As I am moving from add-ins to packages, I always like to learn how to do things using native services of Visual Studio instead of using the automation model (EnvDTE). There is an area of Visual Studio extensibility, the debugger, that is very powerful but normally extensions don’t have to use, except maybe to know which mode (design-time, debug-time, run-time) the IDE is, and when the mode changes, because maybe some commands or features should be enabled/disabled based on the IDE mode.

Eight years ago I wrote how to do that using the automation model in this article:

HOWTO: Guessing the IDE mode (design, debug or run-time) from a Visual Studio add-in or macro

Today I have written a small equivalent article doing the same using the IVsDebugger native service:

HOWTO: Guessing the IDE mode (design, debug or run-time) from a Visual Studio package

I have created two new articles/samples from a question that I addressed in the StackOverflow forum, about unloading / reloading a project programmatically. Using the automation model (EnvDTE) I knew the answers since many years ago:

DTE.ExecuteCommand(“Project.UnloadProject”)
DTE.ExecuteCommand(“Project.ReloadProject”)

However, that approach requires that the project is selected previously in the Solution Explorer. Furthermore, having migrated my MZ-Tools add-in to a Visual Studio package I am no longer happy when I have to use the old automation model and I am eager to investigate how to do things using native services. Alas, the investigation is never easy. In this case the IVsSolution interface provides the CloseSolutionElement method, which is not intuitive because it serves to unload many things, from the solution to a document, and certainly a project too. And it doesn’t seem to provide a method to reload a project. So, I opened the MSDN documentation for IVsSolution2, IVsSolution3, IVsSolution4, IVsSolution5 and IVsSolution6 interfaces and lo and behold, the IVsSolution4 interface has the answers in the UnloadProject / ReloadProject methods. If you remember, Visual Studio 2012 introduced asynchronous solution loading (something that seemed to start in Visual Studio 2010), so the new IVsSolution4 interface introduced quite a few methods that helps with that area. So, here are the samples:

HOWTO: Unload a project from a Visual Studio Package

HOWTO: Reload a project from a Visual Studio Package

Both methods require the project guid that identifies the project in the solution (not to confuse with the project type guid). You can get the project guid from a IVsHierarchy that represents a project calling the GetProperty method with the __VSHPROPID.VSHPROPID_ProjectIDGuid property. For VS 2010, alas, when the project is unloaded the “hierarchy stub” that represents the unloaded project in the solution doesn’t implement that property (it does in VS 2012 and higher). So, the second article applies to VS 2012 and higher (because it starts with an unloaded project as the initial condition), while the first could apply also to VS 2010.

Finally, for completeness sake, given a IVsHierarchy that represents an unloaded project you can get the unload reason calling the GetProperty method with the __VSHPROPID5.VSHPROPID_ProjectUnloadStatus property, which should return a value of the _VSProjectUnloadStatus enumeration.

The usual way to create toolwindows in a package is described in my last post HOWTO: Create a toolwindow with a ToolWindowPane class in a Visual Studio package. While with add-ins only a usercontrol was required, with packages you need the usercontrol and a class that inherits from ToolWindowPane. That is, two files. When I first learned this, I found it somewhat overkill. But when I started to migrate my MZ-Tools add-in to a package, which has quite a few toolwindows, I found it totally overkill. Furthermore, requiring to decorate the package with a ProvideToolWindow attribute for each toolwindow defeats the 3rd strategy that I exposed in Strategies migrating from Visual Studio add-ins to packages, in which a core plug-in provides the features (and therefore the usercontrols for toolwindows) and a host adapter provides the communication between the host (Visual Studio) and the core plug-in. The host adapter is not aware of the features implemented by the core plug-in, and therefore it shouldn’t use specific toolwindows classes or attributes. I am aware that the ProvideToolWindow attribute and the class that inherits ToolWindowPane serve a purpose which was not available for toolwindows created by add-ins: to show automatically when VS is launched the toolwindows that were open in the last VS sessions. So, the initialization of the toolwindow must be contained in a class and not in the “click event” of the command that shows the toolwindow. But it happens that add-ins can provide that functionality too with minimal effort: when unloaded the add-in stores which toolwindows were open and when it is loaded again it shows them. Version 7.0 of MZ-Tools, being an add-in, offered this feature since it was released in 2012.

So, I wanted to create toolwindows in my MZ-Tools package like I was doing in my MZ-Tools add-in. While you can use the automation model (EnvDTE) from a package, alas, the EnvDTE80.Windows2. CreateToolWindow2 method is among the few ones that cannot be used from a package because it requires an EnvDTE.AddIn parameter, that a package cannot provide. Fortunately, the the IVsUIShell interface provides a CreateToolWindow method that can be used from packages. In this new article (equivalent to HOWTO: Create a dockable toolwindow from a Visual Studio .NET add-in) I show how to use it:

HOWTO: Create a toolwindow without a ToolWindowPane class in a Visual Studio package
http://www.mztools.com/articles/2015/MZ2015005.aspx

Creating a package with a toolwindow using the package wizard is easy because the wizard provides you an option to do it:

However, the steps to create a second toolwindow are not evident. And even if you figure out the steps, knowing what they do may be difficult. And if you come from the add-ins space (where toolwindow creation uses an easier approach), toolwindows of packages is difficult stuff. This question has appeared twice in the StackOverflow forum in the last days.

I have written the following article to explain the stuff generated by the wizard when you request the toolwindow option, how the pieces are connected, and why each piece is required:

HOWTO: Create a toolwindow with a ToolWindowPane class in a Visual Studio package
http://www.mztools.com/articles/2015/MZ2015004.aspx

In my next post/article I will explain a different approach to create toolwindows in a package, without a ToolWindowPane (hence the title of this article).
